Warrior 700kg Powered Counterbalanced Crane

The Warrior 900kg Full Electric Rotating Counterbalanced Crane with 360 degree slewing jib is a mobile free-standing workshop crane which has the ability to safely slew its jib through 360 degrees.
The built-in ballast weight which counterbalances the crane jib is mounted on a precision engineered slewing ring allowing maximum accessibility.
It has a five function hydraulic distributor for adjustable jib lifting, lowering, extension and retraction.
Lowering speed can be reduced.

The lifting system is full electric with a key switch voltmeter with emergency stop button and lockable rotation.

Counterbalanced floor cranes with a high capacity slewing jib are the ideal solution for modifying layouts without constraints.

Capacity:- 900kg/450kg/250kg
 Lift Height:- 3180mm
 Overall Dimensions (l x w x h):- 2090 x 950 x 1550mm
 Battery:- 2 x 12V/120Ah Lead Acid
 Charger:- 24V/15A
 Fully Charge Time:- 8 Hours
 Controller:- 2207A-5102
 Drive Motor:- 24V/1000W
 Lift Motor:- 245V/2000W
 Wheel Base:- 1600mm
 Handle Height:- 1300mm
 Drive Wheel:- 250 x 80mm diameter
 Front Wheel:- 200 x 50mm diameter
 Load Drive Speed:- 4.0km/h
 Unload Drive Speed:- 4.5km/h
 Load Gradeability:- 5%
 Unload Gradeability:- 10%
 CE Marked
